AC-powered lifting with manual travel — safe stacking and movement of palletised loads in warehouses, factories, stores, and production areas. Available in Single Mast and Double Mast Telescopic models, custom-built to your application.
Nandi AC Stackers are designed for the safe lifting, stacking, and movement of palletised loads in warehouses, factories, stores, and production areas. Combining manual travel with AC-powered lifting via a 2 HP, 3-phase motor and reliable power pack, they deliver efficient vertical lifting with greatly reduced operator effort — with a three-point steering system for easy handling even in tight spaces.
Built with a rigid structure that resists distortion under heavy load, a reinforced 16 / 20 mm MS carriage plate supported by two chains, and polyurethane-coated support rollers for smooth travel. Safety is built in — overload relay, proximity sensors for cut-off positioning, and a hydraulic overload relief valve. Available in Single Mast (lift heights 500 – 2,000 mm) and Double Mast Telescopic (500 – 4,000 mm) models, in custom-built sizes to suit your requirement.
| Rated Capacity | 250 kg to 2,000 kg |
| Mast Type | Single Mast / Double Mast Telescopic |
| Lift Height — Single Mast | 500 – 2,000 mm |
| Lift Height — Double Mast | 500 – 4,000 mm |
| Lowered Height | 100 mm |
| Fork Length | 500 – 1,500 mm |
| Fork Width | 500 – 1,500 mm |
| Width of Each Fork | 100 mm / 125 mm / 150 mm |
| Movement | Manual |
| Lifting Method | AC Power Pack |
| Lift Motor Rating | 2 HP, 3-Phase — Flange Mounted |
| Power Arrangement | Control Panel & Accessories Provided |
| Carriage Plate | 16 / 20 mm Reinforced MS Plate |
| Wheel Options | Nylon / Cast Iron / Polyurethane |
| Safety Features | Overload Relay · Proximity Sensors · Overload Relief Valve |
The right tool for efficient vertical lifting — safe pallet stacking, loading and unloading, and smooth internal material movement across warehouses, stores, factories, and production units.
Pallet lifting and stacking in warehouses — placing goods at different rack heights with smooth, AC-powered vertical lift.
Efficient loading and unloading operations with reduced operator effort — dependable lifting for repetitive handling cycles.
Material movement in stores and production areas — manual travel with three-point steering for easy handling in tight spaces.
Internal pallet handling in factories and industrial units — built for continuous use in demanding working conditions.
Select the specifications that match your application. Our team will prepare a tailored quote based on your configuration.
